CSafe RKN RKN Unit The first unit of its kind with FAA approval for use on the upper and lower decks of aircraft, expanding the lanes and flights available to our partners. View and Download Precor C936i owner's manual. Hours of Use, Software. USING CSAFE STANDARD EQUIPMENT The C936i is fully compatible with CSAFE protocols.

C Safe Protocol

Advertisement

Programmaboekje template. Tasteful Tapestry Frame printable invitation template. Customize, add text and. We've rounded up some classy minimalist templates that will help you take the guesswork out of what to include on your architecture business card. Programmaboekje - Google zoeken. More information. Wedding Album Template @creativework247 #WeddingAlbums. More information.

Related Manuals for Precor C936i

• Treadmill Precor C934 Owner's Manual
  Commercial treadmill (60 pages)
• Treadmill Precor C932i Service Manual
  (75 pages)
• Treadmill Precor C944 Service Manual
  (46 pages)

• Treadmill Precor C966i Service Manual
  (55 pages)
• Treadmill Precor C954 Owner's Manual
  Commercial treadmill (53 pages)
• Treadmill Precor C954 Owner's Manual
  Commercial treadmill (56 pages)

Summary of Contents for Precor C936i

• Page 1 Standard Commercial Treadmill Owner’s Manual..

• Page 2: Important Safety Instructions

  • If you purchased the optional chest strap, review the guidelines found in the Precor Heart Rate Option Owner’s Manual that is supplied with that option.

• Page 3: Safety Approval

  120-volt grounding plug 120V Units and 240V Units Designated for U.S. Markets The C936i treadmill must be connected to a dedicated, grounded circuit. A 20 amp dedicated circuit is recommended. The treadmill is factory-equipped with a specific power supply cord to permit connection to a proper electric circuit as shown in Diagram 1.

• Page 4: Table Of Contents

  Setting a Pause Time Limit .. 25 Viewing the Odometer, Hours of Use, Software Version, Error Log and Serial Number .. 26 Using CSAFE Standard Equipment .. 27 The C936i Display..28 Features on the Display Console .. 28 ® SmartRate Display ..
• Page 5 Inspection .. 46 Cleaning the Equipment .. 46 Aligning the Running Belt .. 47 Storing the Chest Strap .. 48 Servicing the Treadmill .. 48 Long Term Storage .. 48 Commercial Warranty Registration Card .. 49 Commercial Warranty .. 51 Specifications ..

• Page 6: Radio Frequency Interference (rfi)

  Operation of the treadmill in a residential area is likely to cause harmful interference. If this occurs, the user will be required to correct the interference at his or her own expense.

• Page 7: Obtaining Service

  The serial number can be found on the shipping container or on the label near the power receptacle. If you have any questions regarding the treadmill, use the model and serial numbers whenever you call a Precor dealer or Commercial Products Customer Support Representative.
• Page 8 Notes: page 8..

• Page 9: Unpacking The Treadmill

  Devices, such as FitLinxx also be attached. The Precor “touch” heart rate is standard on the C936i and provides two metal strips, called “grips,” on the center portion of the handrails. When a user places both hands on the grips, a heart rate is transmitted to the receiver.

• Page 10: Hardware Kit

  HARDWARE KIT After unpacking the treadmill, open the hardware kit (refer to Diagram 2) and make sure that you have the following items: ❑ (A) four 2-inch long socket head screws — mount upright supports to base ❑ (B) four barrel spacers — place on 2-inch screws ❑..

• Page 11: Setting Up The Treadmill

  INSTALLATION REQUIREMENTS Follow these installation requirements when installing the treadmill. If you do not install the treadmill according to the following guidelines, you could void the Precor Limited Warranty. • Set up the treadmill on a solid, flat surface. Unpack and assemble the treadmill close to where you plan to use it.
• Page 12 3. Move the treadmill. Diagram 3. To properly lift the rear end and roll it on its front wheels, review Diagram 3. To avoid injury to yourself or damage to the unit, ask for help in placing the treadmill where you plan to use it.
• Page 13 Diagram 5 Route the cable. Display cable Right side mounting bracket Route cable through hole. Right side upright support 6. Route the display cable. Diagram 5. Unwrap the cable and remove any kinks. Have an assistant hold the right upright support close to the base while you route the cable through it.
• Page 14 8. Attach the left side upright support to the base assembly. Refer to Diagram 6. Align the upright support with the base assembly mounting bracket and secure it by following steps 7a and 7b. Diagram 7 Install the display console. Display console Display console mounting..
• Page 15 10. Prepare the unit for handrail installation. Diagram 9. For an easier installation, raise the incline to its maximum height by taking the following steps: a. Plug the treadmill into a power outlet and turn the unit ON. b. Stand to the side of the treadmill and press QUICKSTART (see inset).
• Page 16 12. Attach handrails to the side and base brackets. Diagram 11. Important: Attach one handrail at a time. Take the following steps on one side of the treadmill and then, attach the opposite handrail. a. Slide the end of the handrail toward the handrail clamp. Ask your assistant to hold the handrail in place while you insert screw (C) with washer (F).
• Page 17 Display console Heart rate blinking indicator 14. Test the heart rate feature. Diagram 13. a. Turn the unit ON. The Precor banner should appear in the display. b. Face the display and straddle the running belt. PROFILE CALORIES/MINUTE RIES METS..
• Page 18 Note: If the blinking “Hr” does not appear, turn the unit OFF. Recheck the cable connections and ask someone else to try the test (steps a through c). d. When the test is satisfactorily completed, turn OFF the treadmill and continue with the assembly.
• Page 19 17. Tighten all mounting screws with the hex key (H) provided. Diagram 15. Start at the front of the treadmill with the four screws that attach the upright supports to the front panel. See Diagram 15, #1. Tightening these screws first helps pull the rest of the treadmill’s parts into alignment.
• Page 20 When the lift stops moving, press the red STOP button and turn the power switch OFF. 20. Level the unit. Diagram 17. The C936i has adjustable rear feet. Check to make sure that the running surface is level (use a bubble level as shown in Diagram 17).

• Page 21: Turning The Unit On And Off

  22. Plug the power cord into an appropriate power outlet. Refer to Grounding Instructions on page 3. Make sure that the ON/OFF (I/O) power switch, located on the front panel of the treadmill, is placed in the OFF (O) position before connecting to a power source.

• Page 22: Checking The Alignment Of The Running Belt

  (refer to steps 19 and 20 on page 20). 2. Locate the I/O switch at the front of the treadmill and turn the unit ON. 3. Stand beside the treadmill and press QUICKSTART. The running belt starts automatically after the message, “..

• Page 23: Club Information

  • connect to CSAFE compatible devices Note: If your customers are interested in the learning more about the C936i treadmill, you may wish to direct them to the manual available on Precor’s web site (www.precor.com). (The manual that appears on the web site does not contain the information found in this section.)

• Page 24: Determining The Units Of Measure

  1/3 second after pressing the Stop button. (The RESET key may be used in place of the Stop button.) Important: To access Club Custom mode, press Stop while the Precor banner is displayed. Within second, begin pressing the key sequences. If the system does not..

• Page 25: Determining The Club Speed Limit

  SETTING A PAUSE TIME LIMIT Setting a Pause time limit is useful because the treadmill returns to the Precor banner at a selected interval after the Stop key is pressed whether the user planned to return or not.

• Page 26: Viewing The Odometer, Hours Of Use, Software Version, Error Log And Serial Number

  Press ENTER and the number of hours (Hour Meter) that the unit has been in use appears. The C936i notes the passing of minutes, but the numeric value that appears is truncated to the nearest full hour. When either SELECT key is pressed the word “HOURS appears on the display.

• Page 27: Using Csafe Standard Equipment

  USING CSAFE STANDARD EQUIPMENT The C936i is fully compatible with CSAFE protocols. If the unit is connected to a CSAFE master device, the user will be prompted to enter a user ID. Five zeros appear on the display. The left zero blinks to indicate that it is awaiting input. The..

• Page 28: The C936i Display

  The C936i Display The C936i is designed so users can work out with minimal instruction or training. The directions on the console and the prompts on the display will guide a user through the entire workout session. Before the treadmill is used, however, we recommend that you, as club owner or manager, familiarize yourself with it so you can instruct your customers to use it safely and effectively.

• Page 29: Smartrate Display

  The Precor banner is the “starting point” to begin a workout. It indicates that the C936i is ready to accept user entries. If the banner does not appear on the display, press the RESET key. If the display appears blank, make sure that the treadmill is turned ON.

• Page 30: The Setup Mode And The Quickstart Feature

  THE SETUP MODE AND THE QUICKSTART FEATURE The QuickStart feature can be pressed any time during the Setup prompts. See the table below. Note: Default values apply if QUICKSTART is pressed while the Precor banner is displayed. Refer to QUICKSTART on page 34. Press QUICKSTART at The following occurs: the,..

• Page 31: Display Features During A Workout

  AGE prompt The age (1 through 99) that appears on the display becomes the designated age that the C936i uses for SmartRate correct age entry between 1 and 99 is very important if the user plans to utilize the heart rate characteristics of the treadmill.
• Page 32 INCLINE: Displays the selected percent of incline during a workout. The INCLINE ▲ and ▼ keys affect the treadmill’s lift and let the user set an incline between 0 percent and 15 percent. The displayed values change in 0.5 percent increments. Refer to INCLINE ▲▼..

• Page 33: Keys On The Display Console

  WORKOUT SUMMARY display while in Pause mode. If the user presses RESET again, he or she exits the WORKOUT SUMMARY and returns to the Precor banner. Note that if the user presses RESET during the Setup mode, he or she returns to the Precor banner.
• Page 34 If no AGE entry occurs, then SmartRate LED’s light, but are not acti- vated. Note that the chest strap is available through a Precor dealer. Refer to Obtaining Service on page 7.

• Page 35: Changing The Display Features Using The Select Key

  CHANGING THE DISPLAY FEATURES USING THE SELECT KEY The SELECT keys let the user choose which features appear on the display. When a user enters a program, the TIME and PROFILE features are preselected. Each SELECT key affects four different display features. The left SELECT key, causes the indicator light to appear next to TIME, DISTANCE, CALORIES, and INCLINE.

• Page 36: Exercising On The Treadmill

  Exercising on the Treadmill Once the C936i is set up, it is ready to use. There are no complex instructions to follow or mandatory programming steps required to operate the treadmill. The easy-to-understand prompts let the user select a program and specify how long he or she wishes to work out.

• Page 37: Keypad Tips

  Anytime during setup process, press RESET to return to the Precor banner. QUICK STEPS TO WORKING OUT The steps to working out on the C936i are listed below. A short explanation appears on the left with the more thorough description following on the right.
• Page 38 You are given two minutes to review your workout statistics before the display automati- cally resets to the Precor banner. To return to the Precor banner, prior to the two minute time-out, press RESET. 8. Detach the security clip from your clothing and carefully..

• Page 39: Cooling Down After A Workout

  Cooling down for at least three minutes helps provide a smooth transition that allows your heart rate to return to its normal (non-exercising) state. The treadmill automatically initiates a five-minute cool-down period on several of its programs. A prompt appears, indicating that you are in cool down.

• Page 40: Pause, Workout Summary, And Exit Features

  WORKOUT SUMMARY display — provides a two minute time frame in which you can review your workout statistics before the display automatically resets to the Precor banner. The WORKOUT SUMMARY banner can be accessed from the Pause or Cool Down/Pause modes, or by prematurely exiting a program. When you access the workout summary display, workout statistics except TIME, DISTANCE and CALORIES reset to zero.

• Page 41: Programs

  To use the heart rate features you must wear the chest strap while working out unless you are using the C936i with the touch-sensitive handrail grips. The chest strap transmits your heart rate signal to the receiver installed in the display con- sole.

• Page 42: Manual Mode And The Quickstart Key

  Manual program. Default values apply. Refer to pages 30 and 34. • pressing ENTER at the Precor banner. This causes the C936i to display several Setup prompts. At the program prompt, a user selects the MANL program.

• Page 43: Cross Country Program

  INTERVAL PROGRAM The interval program on the C936i lets the user select the rest and work intervals according to his or her training regimen. Each rest interval is followed by one work interval. The user sets the incline and speed for first rest and work interval and the software repeats the intervals throughout the program.

• Page 44: Weight Loss Program

  Note: For the C936i to detect a heart rate, the user must wear the chest strap. The chest strap is optional equipment that can be purchased from a dealer.

• Page 45: Heart Rate Program

  “zone” that the user is in. Note: For the C936i to detect a heart rate, the user must wear the chest strap or hold onto both touch-sensitive grips on the handrails. The chest strap is optional equipment that can be purchased from your dealer.

• Page 46: Maintenance

  Maintenance The C936i is built to withstand the rigors of the health club environment. However, as club manager or owner, you are responsible for cleaning and maintaining the unit’s integrity. If you fail to maintain the treadmill as described below, it could affect or void the Precor Limited Warranty.

• Page 47: Aligning The Running Belt

  Stop key. Contact Precor Customer Support. 5. If the belt needs additional alignment, repeat steps 1 through 4 of this procedure until the belt is properly aligned. 6. Press the red STOP button. To return to the Precor banner, press RESET. page 47..

• Page 48: Storing The Chest Strap

  Refer to Obtaining Service on page 7. LONG TERM STORAGE When the treadmill is not in use for any length of time, turn it OFF. Ensure that the power cord is unplugged from the wall outlet and is positioned so that it will not become damaged or interfere with other equipment or people.

• Page 49: Commercial Warranty Registration Card

  We are confident that you will be pleased with your purchase and that your new Precor equipment will help satisfy your customers’ fitness needs, while helping you meet your business goals. To allow us to serve you better, please take a few moments to complete and return your warranty registration.
• Page 50 ❑ Ellipticals What other brands of cardio equipment do you currently offer (check all that apply): ❑ Life Fitness ❑ True What other Precor equipment do you currently offer (check all that apply): ❑ EFX ❑ Cycle ® ❑ Treadmill ❑..

• Page 51: Commercial Warranty

  To claim under this warranty, the buyer must notify Precor or your authorized Precor dealer within 30 days after the date of discovery of any nonconformity and make the affected product available for inspection by Precor or its service representative.

• Page 52: Specifications

  U.S. and foreign patents for both the mechanical construction and the visual as- pects of its product design. Any party contemplating the use of Precor’s product designs is hereby forewarned that Precor considers the unauthorized appropriation of its proprietary rights to be a very serious matter.

CSAFE (Communications Specification for Fitness Equipment) is a fitness industry-wide communications specification developed in 1997 for exercise equipment. As this specification was originally developed by the company FitLinxx, sometimes it is also referred to as FitLinxx.

Purpose[edit]

The CSAFE specification describes the physical wiring scheme as well as the format of the data frames. The CSAFE protocol is designed to work in a master/slave fashion. A special I/O jack on the exercise equipment accepts a normal 8P8C (RJ-45) plug (although the wiring scheme has no relation to ethernet) wired to a normal RS-232 cable. The CSAFE port also has pins which should be wired to an input audio jack.

Development[edit]

In October, 2000, a CSAFE group was formed within FISA (Fitness Industry Suppliers Association) to help coordinate the continued evolution of CSAFE. This group is led by a steering committee with membership from a broad representation of the industry. The CSAFE protocol is licensed on a royalty free basis to any company, person, or organization wishing to use it.

Wiring Scheme[edit]

Most of the pins from the RJ-45 plug should be connected to a normal RS-232 interface configured for an asynchronous communication mode of 9600 baud with 8 data bits, 1 stop bits and no parity. Hardware handshaking for flow control (CTS as an input to Slave) is not required to support this protocol but is recommended. The equipment jack pinout for this jack is as follows:

Pin positions are counted from 1 to 8 in a left to right direction looking into the RJ-45 socket with the locking tab facing down as shown in the following diagram:

Communications Protocol[edit]

The communications protocol works in two modes: standard and extended. The primary difference between the two modes is that the extended mode adds source and destination address fields to the frame. The standard frame mode would normally be used in the case where there is only one piece of exercise equipment attached to one computer. This mode is primarily useful in a home setting where there is only one piece of exercise equipment and one controlling computer.

The extended mode is intended for use where multiple pieces of exercise equipment are attached to one or more computers via a shared link. This mode is useful in a gym setting with multiple pieces of exercise equipment located far away from the controlling computer. All of the equipment could be connected to a single multiplexing box which in turn connects to the controlling computer over a long cable.

External links[edit]

Csafe Protocol Software
